SERIES 133.00
coupling
Reference Number: 133.00.KT0S.IG038.4EV
| Series | 133 |
|---|---|
| Nominal Width | 6 mm |
| Type | coupling |
| Valve | flat face |
| Seal | FPM (Viton) |
| Surface | electropolish |
| Material | 1.4404 |
| Connection Size | female thread DIN228/1 (BSP) |
| Connection Type | 3/8 |
| Operating Temperature | from -20 °C to 200 °C |
| Pressure Range max. | 15 bar |
| Flow Rate | 1,580 l/min |
| Handling | One-hand coupling |
| Vacuum suitable 0.95 bar | No |
 |
Dimensions / Details
|
Fitting Products |
||||
 |
Series 133.00 |
Article NYV10 plug |
Beschreibung Nominal width 6.0 mm, 1.4404, surface: electropolish, flat face , male thread DIN228/1, 3/8, seal: FPM (Viton) |
|
 |
Series 133.00 |
Article NYV00 plug |
Beschreibung Nominal width 6.0 mm, 1.4404, surface: electropolish, flat face , female thread DIN228/1, 3/8, seal: FPM (Viton) |
|
|
Series 133.00 |
Article NYV20 plug |
Beschreibung Nominal width 6.0 mm, 1.4404, surface: electropolish, flat face , female thread metric, M15x1.5, seal: FPM (Viton) |
|
